Omnidirectional Binocular Vision System 1/1.3-inch CMOS, 48 MP Max Flight Time: Up to 34/45 minutes Max Flight Distance: Up to 18 km Read more
| Aircraft | ||
| Weight (Battery & Propellers Included) | 249 g | |
| Diagonal Size (Propellers Excluded) | Folded (without propellers): 148×94×64 mm (L×W×H) Unfolded (with propellers): 298×373×101 mm (L×W×H) | |
| Max Ascent Speed | 5 m/s (S Mode) 5 m/s (N Mode) 3 m/s (C Mode) | |
| Max Descent Speed | 5 m/s (S Mode) 5 m/s (N Mode) 3 m/s (C Mode) | |
| Max Speed | 16 m/s (S Mode) 12 m/s (N Mode) 12 m/s (C Mode) | |
| Max Tilt Angle | -135° to 80° | |
| Max Wind Speed Resistance | 10.7 m/s | |
| Max Flight Time | 34 minutes (with Intelligent Flight Battery) 45 minutes (with Intelligent Flight Battery Plus) | |
| Operating Temperature Range | -10° to 40° C (14° to 104° F) | |
| Satellite Positioning Systems | GPS + Galileo + BeiDou | |
| Hover Accuracy Range | Vertical: ±0.1 m (with vision positioning) ±0.5 m (with GNSS positioning) Horizontal: ±0.1 m (with vision positioning) ±0.5 m (with GNSS positioning) | |
| Gimbal | ||
| Stabilization | 3-axis mechanical gimbal (tilt, roll, pan) | |
| Controllable Range | Tilt: -90° to 60° Roll: -90° or 0° | |
| Max Controllable Angular Speed | 100°/s | |
| Angular Vibration Range | ±0.01° | |
| Vision System | ||
| Vision System | Omnidirectional binocular vision system | |
| Camera | ||
| Sensor | 1/1.3-inch CMOS, Effective Pixels: 48 MP | |
| Lens | Wide-Angle Camera FOV: 82° Format Equivalent: 24 mm Aperture: f/1.7 Focus: 1 m to ∞ Medium Tele Camera FOV: 35° Format Equivalent: 70 mm Aperture: f/2.8 Focus: 3 m to ∞ | |
| ISO Range | FOV: 82.1° Format Equivalent: 24 mm Aperture: f/1.7 Focus: 1 m to infinity | |
| Mechanical Shutter Speed | 12MP Photo: 1/16000-2 s (2.5-8 s for simulated long exposure) 48MP Photo: 1/8000-2 s | |
| Image Size | 8064×6048 | |
| Still Photography Modes | Single Shot: 12 MP and 48 MP Burst Shooting: 12 MP, 3/5/7 frames 48 MP, 3 frames Automatic Exposure Bracketing (AEB): 12 MP, 3/5/7 frames at 0.7 EV step 48 MP, 3 frames at 0.7 EV step Timed: 12 MP, 2/3/5/7/10/15/20/30/60 s 48 MP, 5/7/10/15/20/30/60 s | |
| Video Recording Modes | Wide-Angle Camera: H.264/H.265 4K: 3840×2160@24/25/30/48/50/60/100*fps FHD: 1920×1080@24/25/30/48/50/60/100*/200*fps 2.7K Vertical Shooting: 1512×2688@24/25/30/48/50/60fps FHD Vertical Shooting: 1080×1920@24/25/30/48/50/60fps Medium Tele Camera: H.264/H.265 4K: 3840×2160@24/25/30/48/50/60/100*fps FHD: 1920×1080@24/25/30/48/50/60/100*/200*fps 2.7K Vertical Shooting: 1512×2688@24/25/30/48/50/60fps FHD Vertical Shooting: 1080×1920@24/25/30/48/50/60fps | |
| Max Video Bitrate | H.264/H.265: 150 Mbps | |
| Supported File Systems | exFAT | |
| Photo | JPEG/DNG (RAW) | |
| Video | 4K: 3840×2160@24/25/30/48/50/60/100*fps FHD: 1920×1080@24/25/30/48/50/60/100*/200*fps | |
| Supported SD Cards | SanDisk Extreme PRO 32GB V30 U3 A1 microSDHC Lexar 1066x 64GB V30 U3 A2 microSDXC Lexar 1066x 128GB V30 U3 A2 microSDXC Lexar 1066x 256GB V30 U3 A2 microSDXC Lexar 1066x 512GB V30 U3 A2 microSDXC Kingston Canvas GO! Plus 64GB V30 U3 A2 microSDXC Kingston Canvas GO! Plus 128GB V30 U3 A2 microSDXC Kingston Canvas React Plus 64GB V90 U3 A1 microSDXC Kingston Canvas React Plus 128GB V90 U3 A1 microSDXC Kingston Canvas React Plus 256GB V90 U3 A1 microSDXC Samsung EVO Plus 512GB V30 U3 A2 microSDXC | |
| Remote Controller | ||
| Operating Frequency | 2.4000-2.4835 GHz 5.170-5.250 GHz 5.725-5.850 GHz | |
| Max Transmission Distance | FCC: 20 km CE: 10 km SRRC: 10 km MIC: 10 km | |
| Operating Temperature Range | -10° to 40° C (14° to 104° F) | |
| Battery | 18.72 Wh (3.6 V, 2600 mAh × 2) | |
| Transmitter Power (EIRP) | 2.4 GHz: < 33 dBm (FCC) < 20 dBm (CE/SRRC/MIC) 5.1 GHz: < 23 dBm (CE) 5.8 GHz: < 33 dBm (FCC) < 14 dBm (CE) < 30 dBm (SRRC) | |
| Charger | ||
| Voltage | 5V | |
| Rated Power | 30W | |
| Intelligent Flight Battery | ||
| Capacity | Intelligent Flight Battery: 2590 mAh Intelligent Flight Battery Plus: 3850 mAh | |
| Voltage | Intelligent Flight Battery: 7.32 V Intelligent Flight Battery Plus: 7.38 V | |
| Battery Type | Li-ion | |
| Energy | Intelligent Flight Battery: 18.96 Wh Intelligent Flight Battery Plus: 28.4 Wh | |
| Net Weight | Intelligent Flight Battery: approx. 77.9 g Intelligent Flight Battery Plus: approx. 121 g | |
| Charging Temperature Range | 5° to 40°C (41° to 104°F) | |
| Max Charging Power | 30 W | |
| App / Live View | ||
| Live View Quality | Up to 1080p/60fps (available when the aircraft is flying in Photo or Video mode) Up to 1080p/30fps (available when the aircraft is flying in Video mode) Up to 1080p/24fps (available when the aircraft is in standby mode on the ground) | |
| Latency | Aircraft + Remote Controller: approx. 120 ms | |
| Warranty | ||
| Warranty | No warranty | |
| Specifications | Descriptions |
|---|---|
